2024 Built Anchor Handling Tug / Supply Vessel 10,000 BHP for Charter or sale.

2024 Built Anchor Handling Tug / Supply Vessel 10,000 BHP for Charter or sale.

Available quantity: 1

orCall +44(0) 7816466923

Description

Vessel name: Van Bang 8

Built year: 2024

Capacity: 10,000 BHP

Length: 60.86 m

Beam: 16.00 m

Draft: 5.50 m

Main engine: 8N280ZLC-15

Power: 3530 kW @ 800 rpm

Bow Thrust: Model: BST 110-FP

Main Generator: Model: CCFJ350-JW x 2 sets

Power: 412 kW @ 1000 rpm

Mooring Generator: Model: CCFJ120J-W x 1 set

Power: 144 kW @ 1500 rpm

Emergency Generator: Model: CCFJ-75-JW x 1 set

Power: 87 kW @ 1500 rpm

Shaft Generator: Model: SB-HW4B-350-6P

Power: 350 kW @ 660 rpm

Voltage: 400 V

Frequency: 50 Hz

Towing Winches: Double Drum Hydraulic.

Roll load: 1500 kN

Support load: 3000 kN

Drum Capacity: 1000 m

Nominal speed: 5 m / min

Anchor: Speke Anchor 2280 CB/T

Anchor Chain: CCS3 @ 36 CB/T549-1996 Total length 440 m

Rescue boats: 6 People capacity.

Rescue boat crane: Type A davit

Life rafts 20 people x 2 Thowing type.

All details and specifications on the attached PDF files.

Contact us at info@heeyas.co.uk

#ahts #vessel #new #tug #lease #rent #charter #sale #ship





Specifications

ManufacturerAHT Vessel
Model10000 AHT
Year2024
ConditionFeatured
Stock NumberS102
